Fitting Your Decking

How to Build Your Timber Deck

Before starting a garden decking project it is important to have a clear plan: this step by step guide explains all the stages involved in creating the perfect timber deck. Building your own timber deck isn't that difficult, but like any DIY job, it requires the right material and tools and some level of skills.

1. Preparation and Groundwork

Check for any drainage problems in the area where you plan to build your deck – these must be resolved before starting. Deck design must maximise airflow through and around the construction to ensure good ventilation.

Carefully mark out the site with builders lines and ensure that it is square. To help create a square deck and determine its overall size, mark out the proposed area using batter boards, pegs and string line. The easiest way to obtain a right-angle is to make a 3'-4'-5' triangle which will give a 90° angle at the corner. Simply measure off a piece of string into 3', 4' and 5' 'unit' lengths with a felt-tipped pen. The units can be in feet or metres, whichever you prefer.

2. Prepare the Site

Do not lay the deck directly onto grass. Remove all turf and cover the ground with a permeable membrane or black polythene. Place gravel on top of this to prevent weeds from growing. If polythene is used, pierce a series of holes in it to allow drainage of any surface water. The finished deck must be at least 2 brick courses below the damp course level if attached to the house. If this is not practical, a gap must be left between the house and deck to aid drainage.

3. Ground Level Deck

A ground-level deck is simply a platform on the ground which is laid onto a level surface. If you are laying your deck on an existing level concrete area, the framing can be placed directly onto this. If you are laying your deck on a non-concrete surface, such as grass or clay, lay the framing on patio slabs for additional stability. It is important that the slabs are laid on either well-compacted ground or virgin soil. The frame is constructed using 150 x 47mm joist timbers. These should be fixed using galvanised nails. Joists should be fixed at 400mm centres for maximum support. These can be fixed with joist hangers or galvanised nails.

4. Raised/Elevated Deck

Elevated decks can be free-standing or attached to a wall or side of a house. A qualified decking professional should be contacted for projects over 600mm. Structural posts of 100 x 100 x 1200mm should be used for raised/elevated decks.

At least half the length of the post should be sunk into the ground and then fixed with concrete or alternatively concrete feet and dry cement can be used.

Decking Joist Spacing

Decking joists should be spaced at 400mm centres. Structural posts should be positioned no more than 1800mm apart. Use a joist and spirit level to mark the ledger height at the wall. Joists are attached to the ledger or double beam with galvanised joist hangers. Place a scrap piece of decking joist material in the joist hanger to set the width and then nail or screw the joist hanger on the inside of each double beam every 400mm. Place the joist inside the hanger, and nail or screw through the hanger into the joist.

Decking Noggins

Noggins are used to keep the joists from twisting or buckling. Measure and square-cut noggins to fit snugly between the joists. Attach these in a staggered manner as shown below at 1200 centres.

5. Fixing Deck Boards

Deck boards should be pre-drilled before screwing to avoid splitting. They should be evenly fixed and slightly spaced to ensure that there is adequate drainage and ventilation and fixed at right angles to the joists. Deck boards can overhang the edge of the joists at the end or can be trimmed flush with the joints. A fascia board can be added for a more decorative finish.

All cut ends, notches and drill holes must be brushed with an End Coat preservative to maintain the integrity of the pressure treatment and to seal the deck material again.

6. Fitting Balustrading

Balustrading should be assembled and fixed to joists before installing deck boards. Balustrading can finish off ground-level decks and must be used on all elevated decks for safety. Building regulations state that balustrading must be 1.1 metres high or above on elevated decks. The maximum recommended length of rails between posts is 1.8 metres. Additional newel posts must be used for longer railing.

Four very popular types of spindle are usually used the Square, Chamfered, Colonial and American and each of them can be installed using a universal hand/base rail shown here. The spindles are held in place simply by fixing the infill strips between each spindle in both the top and bottom rails.

The Colonial and American range can also be installed using the Richard Burbidge installation system. Full details can be found on their website here.

7. Fixing Newel Posts

These are fixed to joists using 100mm landscape screws. If possible, fix the newels so that two faces can be secured through two joists at 90' to each other.

8. Fitting Steps

The stair strings should be positioned at right angles to the deck. The base of the string may need to be cut at an appropriate angle to allow it to sit firmly on the ground, preferably on a solid area. The strings should be set at a maximum distance of 400mm centres. Fix these using galvanised brackets or joist hangers.

The treads should then be fixed through the top face of the deck board using 63mm screws. Treads are made by cutting deck boards to length. Allow 30mm to overhang each string. All cut ends should be treated with end grain preservative.

The information and advice in this article is provided in good faith and is designed to give general information and guidance. Any reliance you place on such information is therefore strictly at your own risk. If in doubt we strongly recommend you seek professional assistance.
